Recom LED Driver, 2 → 35V dc Output, 10.5W Output, 300mA Output, Constant Current Dimmable

RS Stock No.: 667-1651Brand: RecomManufacturers Part No.: RCD-24-0.30/W
brand-logo
View all in LED Drivers

Technical Document

Specifications

Brand

Recom

Output Voltage

2 → 35V dc

Maximum Output Power

10.5W

Output Current

300mA

Dimmable

Yes

Input Voltage

4.5 → 36 V dc

Operation

Constant Current

LED Driver Type

LED Driver

Dimming Operation

0 to 4.35 V dc, PWM

AC or DC Input Voltage

DC

IP Rating

IP67

Current Rating

0 → 300mA

Series

RCD-24

Voltage Rating

36V dc

Number of Outputs

1

Configuration

Enclosed

Primary Type

DC-DC

Power Dissipation

800mW

Standards Met

RoHS Compliant

Country of Origin

Taiwan, Province Of China

Product details

Constant Current LED Driver, RCD-24 Series - Wired

Non-isolated
Drives up to ten 2W power LEDs
Constant current source
Output current accuracy ±2%, Output current stability ±1%
Efficiency up to 96%
Wide input voltage range
Short circuit protection
Compact package
