Recom REC5 Isolated DC-DC Converter, 12V dc/ 420mA Output, 18 → 72 V dc Input, 5W, Through Hole, +75°C Max Temp
Technical Document
Specifications
Brand
RecomOutput Voltage
12V dc
Input Voltage Range
18 → 72 V dc
Power Rating
5W
Input Voltage Nominal
48 V dc
Output Current
420mA
Mounting Type
Through Hole
Number of Outputs
1
Package
DIP 24
Isolation Voltage
2kV dc
Length
32mm
Depth
10.2mm
Series
REC5
Load Regulation
±0.6%
Maximum Temperature
+75°C
Minimum Temperature
-40°C
Medical Approved
Yes
PRICED TO CLEAR
Yes
Country of Origin
Taiwan, Province Of China
Product details
Recom 5W DIP Single/Dual Output Regulated Isolated DC-DC Converter - REC5 Series
Short circuit protected
Regulated output
DIP24 package
UL94V-0 package material
High efficiency (81% typ)
2% voltage setting accuracy
1kVdc (H1 suffix) or 2kVdc (H2 suffix) Isolation
Pi-network input filter
4:1 wide input range
Single and dual output options
Standards
EN60950-1, UL60950-1, EN60601-1
