TE Connectivity, 3650, 0603 (1608M) Wire-wound SMD Inductor 100 nH ±5% Wire-Wound 400mA Idc Q:34
Technical Document
Specifications
Brand
TE ConnectivityInductance
100 nH
Maximum dc Current
400mA
Package/Case
0603 (1608M)
Length
1.8mm
Depth
1.12mm
Height
1.02mm
Dimensions
1.8 x 1.12 x 1.02mm
Tolerance
±5%
Maximum DC Resistance
580mΩ
Series
3650
Maximum Self Resonant Frequency
1.4GHz
Minimum Quality Factor
34
Inductor Construction
Wire-Wound
Maximum Operating Temperature
+125°C
Minimum Operating Temperature
-40°C
Product details
Tyco 0603 3650 Series Wire Wound Inductors
0603 format
Wire-wound construction
High Q factor
High self-resonant frequency
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
BD 1.785
BD 0.178 Each (In a Pack of 10) (Exc. Vat)
BD 1.963
BD 0.196 Each (In a Pack of 10) (inc. VAT)
Standard
10
BD 1.785
BD 0.178 Each (In a Pack of 10) (Exc. Vat)
BD 1.963
BD 0.196 Each (In a Pack of 10) (inc. VAT)
Standard
10
Stock information temporarily unavailable.
Please check again later.
| quantity | Unit price | Per Pack |
|---|---|---|
| 10 - 90 | BD 0.178 | BD 1.785 |
| 100 - 240 | BD 0.131 | BD 1.312 |
| 250 - 490 | BD 0.121 | BD 1.208 |
| 500 - 990 | BD 0.116 | BD 1.155 |
| 1000+ | BD 0.110 | BD 1.102 |
