Amprobe 30XR-A Handheld Digital Multimeter

Brand

Product Type

Multimeter

Multimeter Type

Handheld

Model Number

30XR-A

Display Type

Digital

Resistance Resolution

100mΩ

Functions Measured

DC Current, Diode, Resistance, AC Current, Battery Test, AC Voltage, DC Voltage

Maximum DC Voltage Measurement

600V dc

Maximum Resistance Measurement

20mΩ

True RMS

No

DC Voltage Accuracy

±1% rdg + 1 Digits

DC Current Accuracy

±2 % rdg + 3 Digits

AC Voltage Accuracy

±1.5 % rdg + 4 Digits

AC Current Accuracy

±2.5 % rdg + 4 Digits

DC Voltage Resolution

100 μV dc

AC Voltage Resolution

100μV ac

AC Current Resolution

0.1μA ac

DC Current Resolution

0.1μA dc

Maximum Frequency

500Hz

Power Source

Battery

Minimum Operating Temperature

0°C

Resistance Measurement Accuracy

±2 % + 5 Digits

Battery Life

200h

Maximum Operating Temperature

45°C

Width

92 mm

Length

196mm

Weight

426g

Standards/Approvals

No

Height

60mm

Safety Category Level

CAT III, CAT II

Safety Category Voltage

500V

Country of Origin

Taiwan, Province Of China
