Belden1885ENH, 500m Cat7, Grey, S/FTP Shielded, Unterminated LSZH Sheath
Technical Document
Specifications
Brand
BeldenSeries
1885ENH
LAN Category
Cat7
Length
500m
Terminated/Unterminated
Unterminated
Shield Type
S/FTP
Shielded/Unshielded
Shielded
CPR Certification
Dca
Sheath Colour
Grey
Outer Sheath Material
LSZH
Core Strands
1/23
Fire Behaviour
Low Smoke Zero Halogen (LSZH)
Outer Diameter
7.7mm
American Wire Gauge
23 AWG
Number of Strands
1
Capacitance
40pF/m
Conductor Strand Type
Solid
Cable Shape
Multicore
Standards Met
Euroclass Dca-s2 d1 a1
Current Rating
1.4 A
Cross Sectional Area
0.26 mm²
Voltage Rating
72 V dc
Country of Origin
Hungary
Product details
Belden 1885ENH - Category 7 Nonbonded-Pair ScTP Cable
CAT7 (1000MHz), 4-Pair, S/FTP shielded, Premise Horizontal Cable, 23 AWG solid bare copper conductors, Foam Polyolefin insulation, each pair with Beldfoil® shield, overall tinned copper braid shield (30% coverage), LSZH jacket.
Features and Benefits
·4 individually shielded twisted pairs
·23AWG solid bare copper conductor insulated in polyethylene
·Tinned copper braided screen
·Low smoke zero halogen (LSZH) jacket
·Operating temperature -20°C to +60°C
·Complies with ISO/IEC 11801 2nd edition and prEN 50288-3-1
Applications
This Cat7 cable is used for horizontal and building backbone. Supports current and future Cat6a and Cat7 appplications such as: 10 gigabit ethernet (10GBase-T), gigabit ethernet (1000Base-T), 100 Base-T, 10 Base-T, FDDI and ATM.
Standards
ISO/IEC 11803; EN 50173; TIA/EIA 568-A-5 Enhanced
BD 697.472
BD 697.472 1 Reel of 500 Metres (Exc. Vat)
BD 767.219
BD 767.219 1 Reel of 500 Metres (inc. VAT)
1
BD 697.472
BD 697.472 1 Reel of 500 Metres (Exc. Vat)
BD 767.219
BD 767.219 1 Reel of 500 Metres (inc. VAT)
1
Stock information temporarily unavailable.
Please check again later.
