Fujitsu PCB Mount Power Relay, 24V dc Coil, 6A Switching Current, SPDT
Technical Document
Specifications
Brand
FujitsuCoil Voltage
24V dc
Contact Configuration
SPDT
Mounting Type
PCB Mount
Switching Current
6A
Number of Poles
1
Latching
No
Terminal Type
PCB Pin
Maximum Switching Voltage AC
250V ac
Maximum Switching Voltage (AC)
250V ac
Length
28mm
Coil Resistance
3390Ω
Coil Power
170mW
Depth
5mm
Height
15mm
Life
50 x 10³ Operations
Contact Material
Silver Alloy
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+85°C
Isolation Coil To Contact
6kV
Maximum Switching Power AC
1.5 kVA
Maximum Switching Power DC
144 W
Application
Power
Country of Origin
China
Product details
FTR-LY Series Power Relay
FTR-LY Series power relay from Fujitsu feature a slim profile (5 mm) for high density mounting
Silver alloy contacts
Contact Rating 6 A @ 250 V ac / 24 V dc
Approvals
VDE, SEMKO, FIMKO, DEMKO, NEMKO
Standards
UL, CSA
