HARWIN Shorting Link Male Straight Blue Closed Top 2 Way 1 Row 5.08mm Pitch
Technical Document
Specifications
Brand
HARWINType
Closed Top
Number Of Contacts
2
Pitch
5.08mm
Gender
Male
Colour
Blue
Number Of Rows
1
Length
9.5mm
Width
12.7mm
Depth
3.2mm
Contact Material
Brass
Contact Plating
Gold
Orientation
Straight
Product details
Harwin D308 Series 1mm Ø Shorting Link Plugs
D308 series 1mm diameter insulated and un-insulated shorting link plugs with a variety of leg pitches and insulation colours. These D308 insulated shorting link plugs have a high performance gold plated brass finish and a colour coded PBT UL94V-0 housing. The insulated versions are not designed for direct soldering to the the PCB but can be used with PCB sockets in hardware programming applications. The D308 un-insulated links can be soldered directly onto a PCB for permanent linking.
Part numbers D308-X-97, D308-X-98 and D308-X-99 are insulated versions
