MEAN WELL Switching Power Supply, RPT-60D, 5 V dc, 12 V dc, 24 V dc, 1 A, 3.5 A, 500 mA, 47.5W, Triple Output, 127
Technical Document
Specifications
Brand
Mean WellOutput Voltage
5 V dc, 12 V dc, 24 V dc
Output Current
1 A, 3.5 A, 500 mA
Power Rating
47.5W
Number of Outputs
3
Input Voltage
127 → 370 V dc, 90 → 264 V ac
Mounting Type
Chassis Mount
Package Type
Open Frame
Length
101.6mm
Width
50.8mm
Medical Approved
Yes
Depth
29mm
Maximum Temperature
+65°C
Minimum Temperature
-20°C
Weight
150g
Country of Origin
China
Product details
RPT-60 Series, Universal Input, 2x4inch, Triple Output
Miniature size 2x4 inch, high power density
High efficiency, long life and high reliability
Universal input voltage 90-264Vac, 127-370Vdc
Medical safety approved
Low leakage current <200μA
Harmonic current compliance to EN 61000-3-2
EMC meets EN 55022 Class B
Short circuit, overload and overvoltage protection
10% extra 'peak current' rating for 10 seconds, on all outputs
Approvals
TUV, CB, UL recognised component for Canada & US
Standards
EN 60601-1, UL 60601-1
