TE Connectivity PCB Mount Power Relay, 24V dc Coil, 8A Switching Current, SPDT
Technical Document
Specifications
Brand
TE ConnectivityCoil Voltage
24V dc
Contact Configuration
SPDT
Mounting Type
PCB Mount
Switching Current
8A
Number of Poles
1
Series
MSR
Latching
No
Terminal Type
Through Hole
Maximum Switching Voltage AC
400V ac
Length
30mm
Coil Resistance
2270Ω
Coil Power
254mW
Height
15mm
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+85°C
Isolation Coil To Contact
4kVrms
Contact Material
Silver Alloy
Depth
10mm
Maximum Switching Power AC
2 kVA
Application
Power
Country of Origin
Mexico
Product details
Power PCB relay, MSR relay, 8 A, 1-pin NO or CO relay
Features:
Neutral DC voltage coil monostable
Washproof
High inrush currents with AgSnO contact
4 kV / 8 mm coil contact
Protection class II
Ambient temperature up to 85 °C at 8 A
Certified: VDE, UL, CSA, SEV, SEMKO, SETI
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
BD 30.962
BD 1.548 Each (In a Tube of 20) (Exc. Vat)
BD 34.058
BD 1.703 Each (In a Tube of 20) (inc. VAT)
20
BD 30.962
BD 1.548 Each (In a Tube of 20) (Exc. Vat)
BD 34.058
BD 1.703 Each (In a Tube of 20) (inc. VAT)
Stock information temporarily unavailable.
20
| Quantity | Unit price | Per Tube |
|---|---|---|
| 20 - 20 | BD 1.548 | BD 30.962 |
| 40 - 80 | BD 1.469 | BD 29.380 |
| 100 - 180 | BD 1.322 | BD 26.442 |
| 200 - 480 | BD 1.192 | BD 23.843 |
| 500+ | BD 1.062 | BD 21.244 |
